DESIGN

Apache Design

Concept

Inspired by Shark, the deadliest predator, the RR 310, is based on the 'Akula Concept'.

Apache Design

Crafted to Impose

Inspired by the deadliest predator – the Shark. The Apache RR310 is conceptualized to have an aggressive and ready-to-attack silhouette which is aided by a raked-high tail and ‘Mass- Forward and Minimalist- Tail’ design.

Apache Design

Crafted for Power

The 2020 Apache RR310 is equipped with state-of-the-art Electronic throttle control (ETC) consisting of electronic throttle grip, electronic throttle body (ETB) and electronic control unit (ECU).

Apache Design

Crafted by the Wind

Extensive designing and testing in a state-of-the-art wind tunnel has yielded the best-in-class coefficient of drag to achieve maximum downforce, minimum wind blast and higher top speed.

Apache Design

Racing Origin Trellis Frame

Light weight trellis frame offers best structural efficiency for excellent dynamic response.

Apache Design

SmartXConnect & TFT Display

The intelligent connected system displays in-depth ride analysis, race telemetry, feature dedicated interfaces, graphics for the 4 ride modes and a lot more.

FEATURES

Unique Reverse Inclined DOHC Engine

The race-derived 310cc powerplant provides a compact engine layout resulting in mass centralization delivering best-in-class Power-to-Weight ratio.

Throttle-By-Wire

2020 Apache RR 310 is equipped with state-of-the-art Electronic throttle control (ETC) to provide precise performance on track.

Dual Channel ABS

The Dual-channel ABS is the perfect synthesis of performance and functionality. The ABS prevents wheel lock, and rear wheel liftoff protection.

Liquid-Cooled Oil-Coolant Technology

Apache RR 310 has 23 rows of tubes for optimized cooling efficiency keeping the high revving engine at optimum temperature delivering maximum performance.

Bi-Led Twin Projector Headlamps

With aggressive brow lines, the first in its class Bi-LED Twin Projector headlamps offer higher intensity enabling you to ride with confidence at higher speeds.

Superior Michelin Road 5 Tyres

The TVS Apche RR 310 is equipped with all-new Michelin Road 5 tyres, featuring Michelin's patented ACT+technology, these tyres provide superior grip for cornering.

Advanced Aerodynamics

Extensive designing & testing in a state-of-art wind tunnel has yielded the best-in-class coefficient of drag to achieve maximum downforce and higher top speed.

Race tuned KYB Suspension

The monoshock with montube floating piston technology has hydraulic stopper with check valves providing precise damping and smooth dynamic response.

Type
SI, 4 stroke, 4 valve, Single cylinder, Liquid cooled, Reverse inclined
Engine capacity
312.2cc
Maximum power
Sport & Track mode - 25kW @ 9700rpm
Urban & Rain mode - 19kW @ 7600rpm
Maximum torque
Sport & Track mode - 27.3Nm @ 7700rpm
Urban & Rain mode - 25Nm @ 6700rpm
Fuel injection
Bosch - Closed loop RT-FI
Max speed
160 km/h - Sport and Track mode
125 km/h - Urban and rain mode
Acceleration 0-2sec (speed in km/h)
46.77 km/h
0-60km/h (time in sec)
2.93 s
0-100km/h (time in sec)
7.17 s
Front Suspension
Inverted cartridge telescopic Fork
Rear Suspension
Two arm Aluminium die-cast swingarm
Chassis
Mono tube floating piston gas assisted
shock absorber
Battery
12V, 8Ah
Headlamp
Bi-LED projector, 30W @ 13 V
Tail Lamp
LED 4 W
Instrument cluster
5" TFT screen connected cluster
Fuel Tank Capacity
11 l
Tyre Size (Front)
110/70-ZR17 M/C 54W Tubeless - Michelin ROAD5
Tyre Size (Rear)
150/60-ZR17 M/C 66W Tubeless - Michelin ROAD5
Front Brake
Disc 300mm Petal type with ABS
Rear Brake
Disc 240mm Petal type with ABS
ABS
With 3 ride modes
Brake Fluid
DOT 4
Height
1135 mm
Length
2001 mm
Width
786 mm
Wheelbase
1365 mm
Ground Clearance
180 mm
Saddle Height
810 mm
Kerb Weight
174 kg

Connected Experience

Connected Experience

Crafted to Overcome

The track mode unleashses the full power of the motorcycle, and optimises the ABS response for the racer to brake late into corners with confidence and ease. The display clears up to only show a vertical tachometer, relevant racing telemetry such as lap times and top speed, and suspends other notifications.

The Smartconnect app displays a detailed post race analysis, directly on your smartphone.

Connected Experience

Connected Experience

Digi Docs

An intelligent feature on the Apache RR310 to store/transfer images and documents from the TVS Connect App to Cluster. You can now store and view up to 3 documents like RC card, Driving license etc on your cluster.

Connected Experience

Connected Experience

Intelligent Cluster Features

Dynamic rev limit indicator to alert the rider depending on the engine temperature and rev limit for enhancing the safety and durability of the engine.

Overspeed indication to warn the rider as per set speed limit (rider defined.)

Day trip meter to track and display daily ride statistics like distance covered, time traveled, average speed, top speed, fuel consumed and a lot more.

Connected Experience

Connected Experience

Crafted to Overcome

The control cubes on the handlebar, allows you to instinctively switch between ride modes with the touch of button while you are on the go. Control cubes also helps the racer to navigate through the Multi Information Race Computer giving access to a host of essential information and personalization widgets.

Connected Experience

Connected Experience

Crafted to Overcome

The Smartconnect app links your smatphone and to your race machine. The cutting-edge Bluetooth connected app offers up a range of race analytics and data that allows any racer to review their racing style and constantly improve it on the track. The app displays a detailed post-ride/race analysis which includes statistics like distance covered, gear shifting points, best lap record, G-Force, interactive tour map plot, ride pattern analysis, and much more.

Connected Experience

Connected Experience

Crafted to Overcome

Tuned feature for urban and rain mode riding, GTT+ enables an extremely smooth and controlled ride. With this feature, one can put the vehicle in motion with a slow release of the clutch lever, without the throttle operation. This eliminates the synchronization of the clutch lever and throttle lever, further eliminating engine stalling. The maximum speed with GTT+ without throttle in Urban and Rain mode:

Gear No. 1 2 3 4 5 6
Vehicle Speed 11 17 25 29 33 37
